One of the best and cheapest in the class of water purifiers. Hi-Tech has sold more than 1 million plants in Orion type body. The first water purifiers which most of the people have bought when Hi-Tech launched its Reverse Osmosis technology to India. We have come up with the same model but with new design and colors option available, we want the customer to match their purifiers with their desired colors.
|Applications||Bore-well , Municipal Corporation , Tanker|
|Dimension||320 x 320 x 420 mm|
|Inlet Water Pressure / Temp (Max)||3 kg/cm^2 or 42.7 Psi / 40 c or 104 F|
|Inlet Water Pressure / Temp (Min)||0.3 kg/cm^2 or 4.3 Psi / 10 c or 50 F|
|Input Power Supply||Single Phase 220V Ac / 50 Hz|
|Total Power Consumption||60w|
|Body Material||Food Grade ABS Plastic|
|Installation Type||Wall Mount Or Counter Top|
|No. Of Free Service||2 Per Year|
|Purification Water Flow Rate||15 Litre / Hour|
|Stage||5 Stage Water Purifier ( RO + UV + TDS Controller )|
WHEN TECHNICIANS INSTALL THE RO PLAN MAINTAIN THE MINIMUM 6FT DISTANCE BETWEEN THE STORAGE TANK TO RO PLAN.
CHANGE PRE SEDIMENT FILTER , CHECK ALL INLINE SET , TANK FILL UP AND EMPTY PROCESS , CHECK TDS OF TAP WATER AND RO WATER, CHECK LEAKAGE
CHECK CARBON FILTER AND MEMBRANE AND REPLACE IT. WHEN GROTH OF BACTERIA IN TANK THEN CLEAN THE TANK OF RO.
WHEN LEAK AT FITTING AND THREADED END CAP LEAK THEN REMOVE THE CONNECTOR AND APPLY THE TEFLON AND FIT IT , AND SET O-RING AND TIGHTEN.
WHEN SUPPLY OF WATER OFF THAT TIME CHECK THE INLET WATER SUPPLY. WHEN SV OR FR DAMAGE OR OPEN THAT TIME CHECK IT AND REPLACE IT.
